ACHP80P – Aluminium

ACHP80P is a 2mm gauge, 100mm wide, heavy-duty cover plate produced from aluminium chequer plate. Supplied with a PVC packer (P) making the cover plate suitable for heavy-traffic commercial installations.

Supplied off-centre drilled for mechanical fixing sing size 8 screws. Available centre drilled or undrilled to special order. Fixings not supplied.

Although the use of a packer (P) is advised, we also offer the cover plate without a packer. Product reference: ACHP80.

Other sizes are available to special order.

Technical Specification

Mill Chequer Plate
Suitability

Heavy contract situations such as for use in hotels, pubs, cafes, clubs, commercial offices, shops, schools and public building, as well as for quality domestic installations.

Lengths Available

2000 mm

Visible Surface When Installed

80 mm

Standard Supply

Off-centre drilled for size 8 screws. Fixings are visible in the finished installation.

Light Reflective Value (Finish)

71.65 Find out more

Finishes

Finish: Mill Chequer Plate

Mill Chequer Plate
